| Power type | DIESEL | DIESEL |
| Rated capacity | 3500kg | 7716lb |
| Load centre | 500mm | 1.64ft |
| Self weight | 8800kg | 19401lb |
| Lifting height | 3000mm | 9.84ft |
| Free lift | 160mm | 0.52ft |
| Fork size (L*W*T) | 1070*125*50mm | 3.51*0.41*0.16ft |
| Mast tilt angle (F/R) | 10°-12°Deg | 10°-12°Deg |
| Overhang(F/R) | 605*625mm | 1.98*2.05ft |
| Min.ground clearance | 260mm | 0.85ft |
| Length to face of fork (without fork) | 3105mm | 10.19ft |
| Overall width | 1693mm | 5.55ft |
| Mast lowered height | 2295mm | 7.53ft |
| Mast extended height (with backrest) | 4162mm | 13.65ft |
| Overhead guard height | 2270mm | 7.45ft |
| Turning radius | 3530mm | 11.58ft |
| Min.right angle stacking aisle width | 5405mm | 17.73ft |
| Travel (Laden/Unladen) | 17/19km/h | 10.6/11.8mph |
| Lifting(Laden) | 420mm/s | 16.54in/s |
| Lowering(Laden) | ＜600mm/s | ＜23.62in/s |
| Max.Drawbar pull (Laden) | 30KN | 30KN |
| Max.Gradeability (Laden) | 20% | 20% |
| Tyre (Front/Rear) | 14-17.5L-14PR/10.0/75-15.3 | 14-17.5L-14PR/10.0/75-15.3 |
| Tread (Front/Rear) | 1630/1550mm | 5.35/5.09ft |
| Wheelbase | 1885mm | 6.18ft |
| Engine Model | Kubota V2403-CR-T-EW04/Yangma 4TNE98 | Kubota V2403-CR-T-EW04/Yangma 4TNE98 |
